Action camera

An action camera drawn as an isometric ink sketch, but in real 3D. Drag to turn it any way you like and see every side, from the lens to the mount fingers underneath. The lines, fills and hatching redraw as it turns. Arrow keys work too, and Reset view brings it back.

Usesthree

About

A GoPro-style action camera drawn like a pencil product sketch, but it's real 3D, so you can turn it to any side. The model is a few dozen simple three.js shapes. Every frame it's drawn twice off screen, noting which way each surface faces, how far away it is and which part it belongs to, and one shader inks a line wherever those change.

The parts, pulled apart
The parts, pulled apart
Which way each surface faces
Which way each surface faces
The lines it finds
The lines it finds
Inspired by
GoPro HERO cameras, and pencil product sketches and LEGO building instructions
Made with
three.js, React and Next.js
